Steel Deck Drawing Interpretation
What Are General Notes — and Why Do They Carry So Much Weight?
The Rules Behind the Drawings
General notes are legally binding instructions placed directly on the structural drawing set. They communicate the Engineer of Record's design assumptions, governing standards, material requirements, and construction expectations. Every plan, detail, section, and note on the drawing must be interpreted through these requirements.
Drawing Information Hierarchy
GENERAL NOTES
↓
Structural Plans
↓
Sections & Details
↓
Fabrication & Installation
What General Notes Typically Control
Codes & Standards
AISC, SDI, AWS, IBC editions, and local amendments
Material Requirements
Steel grades, coatings, thicknesses, and deck properties
Attachment Criteria
Welds, screws, side-lap fasteners, and support attachments
Concrete Requirements
Mix design, density, placement, and composite deck criteria
Special Conditions
Camber, temporary shoring, construction loads, erection sequencing, and project-specific restrictions
READ
Key Principle
Read General Notes Before Anything Else
General notes are not boilerplate text. Every note reflects design intent and establishes how the drawing set should be interpreted. Reviewing plans, sections, or details without first understanding the governing notes is one of the most common causes of RFIs, coordination errors, rejected submittals, and field rework.
Scope Definition Fundamentals
Decoding the Standards Referenced in General Notes
CODE
§
Standards references are instructions, not decoration
One of the first things you'll encounter in steel deck general notes is a list of governing standards. These aren't decorative citations — each reference tells you exactly which edition, which chapter, and which provisions apply to the work.
SDI
Card 01
SDI — Steel Deck Institute
The SDI publishes the primary standards governing steel deck design and installation. The most commonly referenced documents are SDI DDM04, SDI C-2017, and SDI RD-2017.
DDM04
C-2017
RD-2017
Edition specific
Key point: Never assume the latest edition applies unless explicitly stated.
Card 02
AISC 360 — Structural Steel Specification
For composite deck systems, AISC 360 Chapter I governs composite beam and slab design. References to AISC 360 signal that shear connector design, concrete encasement requirements, and composite action assumptions are active parameters.
Chapter I
Composite design
Shear connectors
Concrete encasement
Key point: Cross-reference these sections carefully with the deck layout plans.
Card 03
AWS D1.3 — Structural Welding Code for Sheet Steel
Deck-to-structure welds are governed by AWS D1.3, not the more familiar D1.1. This code covers arc spot welds, arc seam welds, and fillet welds on sheet steel, and it sets the requirements for qualified procedures and proper electrode classifications.
Arc spot welds
Arc seam welds
Fillet welds
Qualified procedures
Key point: The correct minimum weld diameter must be followed for standard deck attachment.
IBC
Card 04
IBC / ASCE 7 — Load and Code References
General notes will cite the governing edition of the International Building Code and often ASCE 7 for load combinations. The edition matters because seismic and wind provisions can change significantly between code cycles.
IBC edition
ASCE 7 loads
Seismic provisions
Wind provisions
Key point: Confirm the locally adopted code edition and resolve any mismatch through RFI.
Material Standards
Material Specifications
Deciphering General Notes
SPECS
Decoding Technical Shorthand
Material notes in a steel deck general note block contain dense, abbreviated technical information. Understanding the shorthand is essential for procurement, fabrication, and inspection.
STEEL
Specification 01
Steel Deck Material Grade
Typically manufactured from ASTM A1008 or ASTM A653. General notes specify minimum yield strength (33 ksi or 50 ksi) and coating designations.
Example: "Deck: A653, Grade 50, G60 coating" indicates 50 ksi yield strength and 0.60 oz/ft² zinc coating.
Specification 02
Deck Gauge and Profile
Notes specify minimum gauge (e.g., 20 ga, 18 ga) and profiles (1.5" Type B, 3" composite). Discrepancies between notes and schedules require an RFI.
Rule: When both a note and a schedule exist, the more restrictive governs.
Specification 03
Concrete Mix Design Notes
Specifies compressive strength (f'c), unit weight (Normal-weight 145 pcf vs. Lightweight 110-120 pcf), and admixture restrictions.
Impact: Incorrect unit weight or f'c can invalidate the effective section properties and structural design.
STUDS
Specification 04
Shear Stud Specifications
Defines material (ASTM A108), headed stud dimensions (typically ¾"Ø), and AWS D1.1 welding requirements for composite action.
Verification: Minimum post-weld stud height must be verified by the field QC inspector.
Critical Note: A discrepancy between plan view callouts and notes is always an RFI condition — never a field judgment call.
Steel Deck General Notes
Attachment Patterns, Fastening Notes & What They Mean in the Field
Small Notes. Major Structural Consequences.
Attachment requirements govern much more than how deck panels are fastened. They directly affect diaphragm strength, load transfer, inspection compliance, and overall structural performance. Understanding what these notes mean in the field is essential for detailers, fabricators, and installers alike.
⚙
Support Attachments
Deck-to-steel welds or fasteners at supports. Verify weld spacing, flute requirements, and sheet-end attachments against structural and diaphragm criteria.
→
↔
Side-Lap Fastening
Side-lap connections help resist diaphragm shear forces. Screw spacing, button punches, or seam welds vary based on lateral load demands.
→
⬒
Perimeter Attachments
Edge angles, closures, and pour stops require dedicated attachment schedules and splice requirements separate from deck field attachments.
Understanding Weld Pattern Shorthand
36/7
=
36" Deck Width
+
7 Welds Per Sheet
ZONE
Critical Coordination Check
Always Compare General Notes to Plan Zones
If the deck plan includes diaphragm designations such as Zone 1, Zone 2, or Zone 3, the fastening requirements may vary across the project. Never assume the general fastening note applies everywhere. Review each zone callout and confirm that support welds, side-lap spacing, and perimeter attachments match the diaphragm schedule and structural design intent.
Field Fastening Is a Structural Design Requirement
Attachment notes are not installation preferences. They are engineered requirements tied directly to load paths, diaphragm performance, structural review approval, and code compliance. Every fastening schedule should be verified against both the general notes and the zone-specific requirements shown on the deck plan.
Steel Deck General Notes
Construction Sequencing, Shoring Notes & Erection Load Limits
Construction Notes Govern Temporary Conditions
Structural deck systems are often most vulnerable before concrete has cured and composite action develops. General notes establish construction-stage limitations that protect the structure during erection, concrete placement, shoring, and load transfer.
Construction Stage Lifecycle
Four Critical General Note Categories
Construction Load Limits
Wet concrete, buggies, pumps, and temporary material storage create loading conditions that can exceed design assumptions. Construction-stage load restrictions must be followed exactly until composite action is fully developed.
Shoring Requirements
Loading limits, shore spacing, support locations, strength requirements, and removal timing must all match the project notes. Early removal can lead to excessive deflection, investigation, and costly remedial work.
Erection Sequence Requirements
Multi-story structures depend on a specific loading sequence. Floors may need to cure before upper floors are loaded. These requirements reflect structural design assumptions and cannot be altered without engineering review.
Camber & Pre-Deflection Requirements
Cambered members are intentionally fabricated with upward curvature. Deck installers must not shim or force-level the framing unless specifically directed, as doing so changes the load path assumed in the design.
QC
Quality Control Checkpoint
Verify Shoring Approval Before Concrete Placement
Before concrete placement begins, confirm that the shoring plan, removal sequence, and construction loading assumptions have been reviewed and accepted by the Engineer of Record. This verification is a critical control point on SDI-compliant projects and helps prevent costly structural deficiencies.
Operational Protocol
Putting It All Together
Field-Ready Checklist
CHECK
A Systematic Approach
Reading general notes effectively requires a systematic approach — not a casual scan. Use this checklist as a protocol every time you receive a new steel deck drawing set.
01
Identify Governing Standards Block
Locate all referenced codes (SDI, AISC, AWS, IBC) and confirm consistency with Division 05 project specifications. Issue an RFI immediately for any conflicts.
02
Extract Material Specifications
Record steel grade, coating type, minimum gauge, and concrete mix details (f'c, unit weight). Flag any discrepancies between notes and procured materials.
03
Map Attachment Schedule to Plan
Cross-reference attachment notes against the deck plan. Identify zone-specific fastening requirements and ensure constructability with on-site equipment.
04
Construction Load & Shoring
Extract load limits and shoring requirements verbatim. Coordinate with concrete superintendent to ensure placement plans comply with EOR limits.
05
Flag All Notes for Field Distribution
Create and distribute summary sheets to installers and site superintendents. Post a laminated copy at the hoist or trailer for maximum visibility.
